Camera

Effective Pixels

1920(H)*1080(V)

TV System

PAL/NTSC

Electronic Shutter

1/25s~1/50,000s , 1/30s~1/60,000s

Sync System

Internal

Usable Illumination

0.01Lux

S/N Ratio

≥50dB

Scanning System

Progressive

Video Output

Network

Lens

Focus Length

2.8-12mm Manual Zoom Lens

Focus Control

Manual

Lens Type

Manual

Pixels

2M Pixels

Night Vision

Infrared Distance

40M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

Ethernet

RJ-45 (10/100-T)

Protocol

IPv4, HTTP, TCP/IP, FTP, NTP, RTSP, UDP, SMTP, DNS, DDNS

ONVIF

Support ONVIF 2.4

P2P

YES, Support QR Code

POE

Optional, Support IEEE 802.3af

WIFI

N/A

Video Delay

0.3S (Within the Lan)

Main Stream

1280*960@30fps

Sub Stream

704*576@30fps, 352*288@30fps

IE Brower

IE6-11, Google Chrome(IE Tab), Firefox(IE Tab)

Smart Phone

iPhone, iPad, Android, Android Pad

Camera Features

Day/Night

Color/ B&W (IR-CUT )

Compression

H.264/JPEG,Support record AVI format.

Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, BLC, FLK(FlickerControl)

Motion Detection

Support

Privacy  Masking

3 Rectangular Zone

WDR

YES

Recording Mode

NVR/NAS/CMS/Web

Language

Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French,Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian

General

Housing

Vandalproof  IP66

Lens Angle Adjustment

YES, Anti-Cut 3-Axis Bracket

IR Cut Filter

YES

Operation  Temperature

-10 ~ +50  RH95% Max

Storage Temperature

-20 ~ +60  RH95% Max

Power Source

POE DC12V±10%,500mA
