Video/Audio Input

IP video input:

|

4-ch

Two-way audio input:

|

1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

Incoming bandwidth:

|

40Mbps

Outgoing bandwidth:

|

80Mbps

Remote connection:

|

128

Video/Audio Output

HDMI/VGA output:

|

1-ch, resolution:
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,
1024 × 768 /60Hz

Recording Resolution:

|

6MP/5MP/4MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Rate:

|

Main stream: 50 fps (P) / 60 fps (N)
Sub-stream: 50 fps (P) / 60 fps (N)

Audio Output:

|

1-ch, RCA (Linear, 1kΩ)

Synchronous Playback:

|

4-ch

Decoding

Live view / Playback:

|

6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Capability:

|

4-ch@1080P

Hard Disk

SATA:

|

1 SATA interface for 1 HDD

Capacity:

|

Up to 4TB for each disk

External Interface

Network Interface:

|

1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface

USB Interface:

|

1 × USB 2.0 and 1 × USB 3.0

Alarm In:

|

4-ch(optional)

Alarm Out:

|

1-ch(optional)

POE

Interface:

|

4 independent 100 Mbps PoE
network interfaces

Max. Power:

|

50W

Supported Standard:

|

AF and AT

General

Power Supply:

|

48V DC

Consumption(without hard disk and POE):

|

≤ 10W

Working Temperature:

|

-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)

Working Humidity:

|

10 % ~ 90 %

Chassis:

|

1U chassis

Dimensions:

|

315 × 230 × 45mm
(12.4 ×9.1 × 1.8 inch)

Weight(without HDD):

|

≤ 1 Kg (2.2 lb)
