IP video input:

8-ch

Two-way audio input:

1-ch, RCA (2.0 Vp-p, 1kΩ)

Incoming bandwidth:

80Mbps

Outgoing bandwidth:

160Mbps

Remote connection:

128

HDMI Output:

1-ch, resolution: 4K(3840*2160)/60Hz, 4K(3840*2160)/30Hz, 1920*1080P/60Hz,

1600*1200/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Recording Resolution:

8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Audio Output:

1-ch, RCA (Linear, 1kΩ)

Synchronous Playback:

8-ch

VGA Output:

1-ch, resolution: 1920*1080P/60Hz, 1280*1024/60Hz, 1280*720/60Hz, 1024*768/60Hz

Live view / Playback:

8MP/6MP/5MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Capability:

8-ch@1080P

SATA:

2 SATA interfaces for 2 HDDs

Capacity:

Up to 6TB capacity for each HDD

Network Interface:

1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface

USB Interface:

Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0

Alarm In:

4-ch

Alarm Out:

1-ch

Power Supply:

100 to 240VAC

Consumption(without hard disk and POE):

≤ 15 W

Working Temperature:

-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)

Working Humidity:

10 % ~ 90 %

Chassis:

385 mm chassis

Dimensions:

385 × 315× 52 mm (15.2" 12.4" 2.0")

Weight(without HDD):

≤ 3 kg (6.6 lb)
