Image Sensor:

1/3" Progressive Scan CMOS

Min. Illumination:

0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR

Shutter time:

1/3 s to 1/10,000 s

Lens:

4mm @ F2.0

Lens Mount:

M12

Day& Night:

IR cut filter with auto switch

Wide Dynamic Range:

120 dB

Digital noise reduction:

3D DNR

Compression Standard

Video Compression:

H.264/MJPEG/H.264+

H.264 code profile:

Main Profile

Video bit rate:

32Kbps~16Mbps

Dual Stream:

Yes


Max. Image Resolution:

2688 × 1520

Rate:

50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)

Image Settings:

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or

web browser

BLC:

Yes, zone configurable

ROI:

Support

Network

Alarm Trigger:

Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm,

Network disconnect ,

IP address conflict, Storage exception

Protocols:

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,

SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

General Function:

One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access

System Compatibility:

ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI

Interface

Audio:

1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model)

Communication Interface:

1 RJ45 10M / 100M Ethernet interface

Alarm:

1x alarm I/O  *only for –S models

On-board storage:

Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

Reset Button:

Yes

Wi-Fi Specification (-W)

Wireless Standards:

IEEE802.11b, 802.11g, 802.11n

Frequency Range:

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth:

20/40MHz Support

Modulation Mode:

802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM

Security:

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transmission Rate:

11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps

Wireless Range:

50m(depend on environment)

General

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

12 VDC , PoE (802.3af Class3)

Power Consumption:

Max. 5W

Impact Protection:

IK10

Weather Proof:

IP67

IR Range:

Up to 30m

Dimensions:

Φ111 × 82 (4.4” × 3.2”)

Weight:

500g (1.1lbs)

NOTE:

"-W" series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support
the 802.1X protocol.
