Standard:

HD-TVI

Sensor:

Progressive Scan CMOS

Matrix size:

2.1 Mpx

Resolution:

1920 x 1080  - 1080p @ HD-TVI

Range of IR illumination:

40 m

IR illuminator power adjustment:

Automatic

Lens:

2.8 mm

View angle:

103 ° (manufacturer data)

101 ° (our tests result)

S/N ratio:

> 62 dB

Video output:

1 Vpp HD-TVI / 75 Ω - HD-TVI, BNC socket

Main features:

EXIR - high-efficiency infrared LEDs technology, which unlike standard IR illuminators with round LEDs,

evenly covers the whole plan of both central vantage points of the scene as well as the corners

ICR - Movable InfraRed filter

BLC - Back Light Compensation

AGC - Automatic Gain Control

Auto White Balance

OSD menu:

"Index of Protection":

IP66

Power supply:

12 V DC / 330 mA

Power consumption:

≤ 4 W

Housing:

Compact, Plastic

Color:

White / Black

Operation temp:

-40 °C ... 60 °C

Weight:

0.44 kg

Dimensions:

226  x 87  x 82 mm

Supported languages:

Manufacturer / Brand:

HIKVISION
