Video/Audio Input

IP video input:

|

16-ch

Two-way audio input:

|

1-ch, RCA (2.0 Vp-p, 1kΩ)

Network

Incoming bandwidth:

|

100Mbps

Outgoing bandwidth:

|

40Mbps

Remote connection:

|

128

Video/Audio Output

HDMI/VGA output:

|

1- ch, resolution:
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz

Audio Output:

|

1-ch, RCA (Linear, 1kΩ)

Decoding

Live view / Playback:

|

1080P /UXGA /720P /VGA /4CIF /DCIF /2CIF /CIF /QCIF

Capability:

|

4-ch@720P, 2-ch@1080P

Hard Disk

SATA:

|

1 SATA interface for 1 HDD

Capacity:

|

Up to 4TB for each disk

External Interface

Network Interface:

|

1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface

USB Interface:

|

2, USB2.0

POE

Interface:

|

8 independent 10 /100 Mbps PoE Ethernet interfaces

Max. Power:

|

120W

Supported Standard:

|

AF

General

Power Supply:

|

48V DC

Consumption(without hard disk and POE):

|

≤ 15 W

Working Temperature:

|

-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)

Working Humidity:

|

10 % ~ 90 %

Chassis:

|

1U chassis

Dimensions:

|

285 × 210 × 45 mm

Weight(without HDD):

|

≤ 1 Kg
