Image Sensor:

1/2.8" Progressive Scan CMOS

Signal System:

PAL/NTSC

Min. Illumination:

0.01Lux @(F1.2,AGC ON), 0 Lux with IR
0.028Lux @(F2.0,AGC ON), 0 Lux with IR

Shutter time:

1/3 s to 1/100,000 s

Lens:

4mm@ F2.0, Angle of view: 85°
(2.8mm, 6mm optional)

Lens Mount:

M12

Day& Night:

IR cut filter with auto switch

Wide Dynamic Range:

Digital WDR

Digital noise reduction:

3D DNR

Video Compression:

H.264/MJPEG

H.264 code profile:

Main Profile

Video bit rate:

32Kbps~8Mbps

Audio Compression:

G.711/G.722.1/G.726/MP2L2

Audio bit rate:

64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2)

Max. Image Resolution:

1920 x 1080

Rate:

50Hz: 25fps(1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps(1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)

Image Settings:

Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser

BLC:

Yes, zone configurable

ROI:

support

3D DNR:

support

Network Storage:

NAS (Support NFS,SMB/CIFS)

Alarm Trigger:

Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis,

Tampering alarm, Network disconnect , IP address conflict, Storage exception

Protocols:

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour

General Function:

One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering

System Compatibility:

ONVIF, PSIA, CGI, ISAPI

Communication Interface:

1 RJ45 10M / 100M Ethernet interface

Alarm Input:

1

Alarm Output:

1

On-board storage:

Built-in Micro SD/SDHC/SDXC slot, up to 128 GB

Wireless Standards:

IEEE802.11b, 802.11g, 802.11n

Frequency Range:

2.4 GHz ~ 2.4835 GHz

Channel Bandwidth:

20/40MHz Support

Modulation Mode:

802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM

Security:

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS

Transmit Power:

11b: 17±1.5dBm @ 11Mbps
11g: 14±1.5dBm @ 54Mbps
11n: 12.5±1.5dBm

Receive Sensitivity:

11b: -90dBm @ 11Mbps (Typical)
11g: -75dBm @ 54Mpbs (Typical)
11n: -74dBm (Typical)

Transmission Rate:

11b: 11Mbps
11g: 54Mbps
11n: up to 150Mbps

Wireless Range:

50m(depend on environment)

Protocols:

IEEE802.11b, 802.11g, 802.11n

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption:

MAX. 4.5W

IR Range:

10 meters

PIR:

Angle: 80°

Dimensions:

72.3×89.9×131.3

Weight:

400g(0.88lbs)
