Technical parameters

Status

Launched into market in May 2018

Control size

Single color 32K：2048*16、1024*32、512*64

Dual color 24K：1536*16、768*32、384*64

Tri color 16K: 1024*16、512*32、256*64、128*128

Storage

2MByte

Software function

Softawre function

group sending/multi-program edit/

multi-area display/multi-lanuage version；

Program quantity

Support 128 programs

Area quantity

Each program maximum support 8 areas

Area type

Weather/Image&text//sub/animation /lunar/ time/dial/timer/sensor areas

Border

Program shine border /Area shine border

Clock

Lunar /Dial/ Chinese and English clock/timer (all support multi-groups)

Display effect

Moving smoothness

It will not get cross lines when move left,

and will not shake when lower the moving speed.
the brightness will not be lower

when move left in a long screen;

program stability

Support adjusting moving speed; high refresh rate,

stable running on screen;

Module compatibility

Module

Support all kinds of single/dual/tri color LED modules

Row driving IC

Support 74HC595, SM16188,etc,

those main stream LED driving chip,

but do not support all PWM chip

Row decoding IC

Support 74HC138 and the modules without row coding
Do not support other row coding chip, will be supported later

Scan mode

Support smart scan,

and support all the scan type from static to 1/32

Module empty spot

Support any empty spot

RGB signal

Support defining RGB signal

Interface

Interface

2 nos T75+2 nos T8+4 nos T12

Communication

WIFI +USB

Sensor interface

IR /temperature/temp&humidity/

brightness sensor socket on board

Important functions

Remote

Support select program/lock screen/

brightness adjustment/power on & off/screen test

Sensor

Support temperature/temp&huidity/brightness sensor

Brightness adjust

16 grade brightness, support manual /timing/auto adjust mode

Remote switch

Support auto timing switch,software/remote switch

Weather report

Support China & overseas weather report

Program group sending

Support program self-adaption

Parameters fast match

Support save and read-back the screen parameters

Any layout

Support arbitrary typesetting rules in Mongolian,

Hebrew, Arabic, etc, easy to make vertical font

Wireless communication

Protocol

Wireless transferring；
Support TCP/IP/UDP
Support router/bridging mode；
Support 802.11b/g/n wireless standard；
Support heartbeat signal, indication of WIFI connection；

Transfer distance

≤200M (suggest ≤100M in application)）

Wireless standard

802.11 b/g/n

Working frequency

2.412GHz-2.484GHz

Antenna

Inside Antenna

Firmware update

Firmware update

support firmware update online

Secondary development

SDK

Support static area development,

supply the c# 、java 、VB、C++  development tools

Electricity parameters

working voltage

5V（3.5V～6V wide working voltage

Max power

≤2W

working  temperature

-40℃～80℃

Software

PC software

LedshowTW

Phone APP

Ledshow
