Image Sensor:

1/3" Progressive Scan CMOS

Min. Illumination:

0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR

Shutter time:

1/25(1/30) s to 1/100,000 s

Lens:

4mm@ F2.0 (2.8mm, 6mm optional)
2048 × 1536:
Angle of view: 86°(2.8mm), 70°(4mm), 43.3°(6mm)
1920 × 1080:
Angle of view: 98.5°(2.8mm), 79°(4mm), 49°(6mm)

Lens Mount:

M12

Adjustment Range:

Pan:0° - 355°, Tilt: 0° - 65°

Day& Night:

IR cut filter with auto switch

Wide Dynamic Range:

Digital WDR

Digital noise reduction:

3D DNR

Video Compression:

H.264/M-JPEG

Bit Rate:

32 Kbps ~ 16 Mbps

Dual Stream:

Yes

Max. Image Resolution:

2048×1536

Rate:

50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720)
60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720)

Image Settings:

Saturation, Brightness, Contrast Sharpeness adjustable by client software or web browser

BLC:

Yes, zone configurable

ROI:

Yes, up to 4 configurable areas

Network Storage:

NAS

Alarm Trigger:

Motion detection, Tampering alarm

Protocols:

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour

Security:

User Authentication, Watermark, IP address filtering, anonymous access

System Compatibility:

ONVIF, PSIA, CGI

Communication Interface:

1 RJ45 10M / 100M ethernet interface

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

12 VDC ± 10%, PoE (802.3af)

Power Consumption:

Max. 5 W (Max. 7 W with IR cut filter on)

Impact Protection:

IEC60068-2-75Eh, 50J; EN50102, up to IK10

Weather Proof:

IP66

IR Range:

Approx. 10 to 30 meters

Dimensions:

Φ127 × 97.5 mm

Weight:

670g
