Image Sensor:

1/3" Progressive Scan CMOS

Min. Illumination:

0.01Lux @ (F1.2, AGC ON), 0 Lux with IR

Shutter time:

1/3 s to 1/100,000 s

Lens:

4mm, 6mm @ F2.0, Angle of view: 83°(4mm) , 55.4°(6mm)

Lens Mount:

M12

Day& Night:

IR cut filter with auto switch

Wide Dynamic Range:

120 dB

Digital noise reduction:

3D DNR

Compression Standard

Video Compression:

H.264/MJPEG/H.264+

H.264 code profile:

Main Profile

Video bit rate:

32Kbps~16Mbps

Dual Stream:

Yes


Max. Image Resolution:

2688 × 1520

Rate:

50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)

Image Settings:

Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or

web browser

BLC:

Yes, zone configurable

ROI:

Support

Network

Network Storage:

NAS (Support NFS,SMB/CIFS), ANR

Alarm Trigger:

Face Detection,Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis,

Tampering alarm, Network disconnect , IP address conflict, Storage exception

Protocols:

TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,

SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour

General Function:

One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering

System Compatibility:

ONVIF (Profile S, Profile G),ISAPI

Interface

Communication Interface:

1 RJ45 10M / 100M Ethernet interface

General

Operating Conditions:

-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)

Power Supply:

12 VDC ± 25%, PoE (802.3af Class3)

Power Consumption:

Max. 5W

Weather Proof:

IP67

IR Range:

Up to 30m

Dimensions:

70×154.2×60.5 mm (2.8” × 6.2” × 2.4”)

Weight:

500g (1.1lbs)
